Clay Paky Sharpy X Frame

The Clay Paky Sharpy X Frame is a multifunction luminaire which takes the best features of the Sharpy line and integrates a four-focal plane shutter system in a lightweight, compact fixture. Powered by a 550W arc lamp, the fixture is extremely bright and produces deep uniform colours. The Sharpy X Frame offers a rotating gobo wheel with eight gobos, a static gobo wheel, four and eight-facet rotating prisms, linear frost, a colour system featuring CMY, CTO and a separated colour wheel, and six beam reducers starting at 0.5°. With a 160mm front lens, proven Clay Paky optics and a zoom range from 3° to 52° (spot mode) and 2° to 29° (beam mode), the Sharpy X Frame can do unparalleled visual effects.

Key features

• Light source: 550W arc lamp
• CRI: 80+ and up to 90 by mixing the CMY wheels
• Output: 18,800 lm
• 160-millimeter diameter front lens
• 3°-52° (spot mode) and 2°-29° (beam mode) linear motorized zoom
• Linear CMY colour mixing & CTO
• 14-color wheel on separate channel
• Rotating gobo wheel with 8 interchangeable glass gobos
• Static gobo wheel with 18 static gobos
• Six beam reducers (down to 0.5°)
• Animation wheel
• Rotating 4-facet & 8-facet prism on dedicated channel
• Motorized iris
• Framing system: 4 focal planes, +/-60° rotation and macro channel control
